Model 型号                                                                                                                LY-3080B

Grindable diameter 可磨直径                                                                                    Φ2~Φ80mm/Φ10~Φ60mm

Grindable length 可磨长度                                                                                         300/65mm

Center height 中心高                                                                                                 115mm

Max workpiece weight 大工件重量                                                                         10kg

Workbench speed 工作台速度                                                                                   0.1~4(r/m）

Grinding wheel line speed 砂轮线速度                                                                       35(m/sec)

Max travel of workbench 工作台大移动量                                                                 320mm

Workbench rotation range 工作台转动范围                                                                   -3°~7°

Inner spindle speed 内圆主轴转速                                                                                15000(r/min）

External grinding wheel size  外圆砂轮尺寸          Max Φ250*25*Φ75mm           Min Φ180*25*Φ75/20*8*20mm

Tail stock taper morse 头尾架                                                                               NO.3

Motor total power 电机总功率                                                                                   3.16kw

Roundness(O.D/I.D) 圆度(外圆/内圆)                                                                           0.002/0.005μm(O.D/I.D )

The surface roughness(O.D/I.D)  表面粗糙度(外圆/内圆)                                            Ra0.25/0.63μm (O.D/I.D )

Machine weight 机床重量                                                                                          1000kg

Machine overall dimensions(LxWxH) 机床外型尺寸(长x宽x高)                                     1360*1240*1000mm
